MCCB 4P TM160D 112-160A 50KA 380/415VAC

To download the product datasheet LV430850 MCCB 4P TM160D 112-160A 50KA 380/415VAC, please click here!

Technical Characteristic:

• Product Code : LV430850
• Brand : Schneider Electric
• Product Name : MCCB 4P TM160D 112-160A 50KA 380/415VAC
• Description : COMPACT NSX160N ADJUSTABLE SCHNEIDER ELECTRIC - LV430850
• Product name : ComPact NSX
• Range of product : ComPact NSX100-250
• Device short name : NSX160N
• Product or component type : Circuit breaker
• Device application : Distribution
• Number of poles : 4P
• [In] rated current : 160 A at 40 °C
• [Ue] rated operational voltage : 690 V AC 50/60 Hz
• Width (W) : 140 mm
• Height (H) : 161 mm
• Depth (D) : 86 mm
• Net weight : 2.6 kg
• Warranty : 12 months

Schneider Electric Compact NSX - Legacy

This Compact NSX160N is a complete 4P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 50kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 160A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 4 poles version (140mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX160N is part of Schneider Electric EcoStruxure Power architecture.
